MONARCH B-3530-0104 HPU,1 Stage,1 gal.,1.6 kW,2 gpm,12VDC 36NE07
Specifications
| Brand | MONARCH |
| MPN | B-3530-0104 |
Hydraulic Power Unit, Circuit Design Single or Double Acting, Power Source - Power Units DC Power, 2.1 hp HP, 12V DC, Full Load Amps 200 A, Pump Stage 1, Max. Pressure 3,000 psi, Nominal Flow 2 gpm, Reservoir Capacity 1 gal, Overall Length 18 1/32 in, Overall Width 8 11/32 in, Overall Height 7 13/32 in Specialty DC hydraulic units are used in applications where complex movement is required. In addition to double-acting control that provides precise control over raising and lowering, specialty power units provide additional control for more complex operations, such as the left/right angle adjustment required for a snow plow.Ã DC hydraulic power units (HPUs) are battery-operated and used to power tail-gate lifts, agricultural and marine equipment, dump trailers, and other portable hydraulic.
